Spécifications techniques

• Gigabit Ethernet RJ-45 Copper ports (10M/100M/1G) - 1000BASE-T : 8
• PoE/PoE+ ports : 8 PoE+ (123W PoE budget)
• Power Supply : External Input 54V 2.4A (130W)
• Power Supply Supported : External, Input 54V 2.4A (130W), Input 54V 1.66A (90W), Input 54V 1.25A (67.5W)
• Form Factor : Desktop/Rackmount/Wall-Mount

Product Specifications

• Gigabit Ports : 8
• Max MAC entries : 4K
• Buffer Size 192KB
• Energy Efficient Enthernet (IEEE 802.3az complaint) : Yes

PoE Support

• 802.3af Ports 1-8
• 802.3at Ports 1-8
• PoE Max Power Per Port : Up to 15.4w for 802.3af and 30W for 802.3at
• Total PoE Power Budget : 123W
• Forwarding modes : Store-and-forward
• Bandwidth : 16Gbps
• Jumbo frame support : Yes
• Acoustic noise (ANSI-S10.12) 0 (fanless)
• Mean Time Between Failures (MTBF) : 2,752,476 hours

Quality of Service (QOS)

• DSCP : Yes
• IEEE 802.1p COS : Yes
• Queue WRR Ratio : 1:3:5:7:8:10:12:15 Weighted Fair Queue (WFQ)

LEDs

• Per port : Speed, Link, Activity, PoE
• Per device : Power Status, PoE Max

IEEE Network Protocols

• IEEE 802.3 Ethernet
• IEEE 802.3u 100BASE-TX
• IEEE 802.3ab 1000BASE-T
• IEEE 802.1p Class of Service
• IEEE 802.3az Energy Efficient Ethernet (EEE)
• IEEE 802.3i 10BASE-T Ethernet
• IEEE 802.3x Flow Control

Physical Specifications

• Dimensions (W x D x H) 236 x 102 x 27 mm
• Poids 0.6 kg

Power Consumption

• Power Supply : External Input 54V 2.4A (130W)
• Power Supply Supported : External, Input 54V 2.4A (130W), Input 54V 1.66A (90W), Input 54V 1.25A (67.5W)
• Max power (worst case, all ports usedline-rate traffic) (Watts) : 130W
• Min power (link-down standby) (Watts) : 1.23W
• Heat Dissipation (max and min) (BTU/hr) : 444.6 BTU/3.69 BTU
• Energy Efficient Ethernet (EEE) IEEE 802.3az : Yes
• Short cable power reduction : Yes
• Auto power-down : Yes
• Fan(s) : 0 (fanless)

Environmental Specifications

• Operating
• Operating Temperature  0° to 40°C (32° to 104°F)
• Humidity  90% maximum relative humidity (RH), non-condensing
• Altitude 10,000 ft (3,000 m) maximum
• Storage
• Storage Temperature  –20° to 70°C (– 4° to 158°F)
• Humidity (relative) 95% maximum relative humidity (RH), non-condensing
• Altitude 10,000 ft (3,000 m) maximum

Electromagnetic Emissions and Immunity / Certifications

• 47 CFR FCC Part 15, SubpartB, Class A
• ICES-003:2016 Issue 6, Class A
• ANSI C63.4:2014
• 55032:2012+AC:2013, Class A
• EN 55024:2010
• EN 61000-3-2:2014, Class A
• EN 61000-3-3:2013
• AS/NZS CISPR 32:2015, Class A
• VCCI-CISPR 32:2016, Class A
• KN 35
• CNS 13438
• Electromagnetic Compliance Class A

Safety Certifications

• Certifications :
• CB. IEC 60950-1:2005(ed.2) + A1:2009 + A2:2013
• UL/cUL Listed; UL60950-1, 2nd Ed. 2014; CAN/CSA C22.2 No. 60950-1-07, 2nd Ed.
• 2014
• EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013
• AS/NZS 60950.1:2015
• KN 32
• CNS 14336-1

Warranty and Support

• ProSAFE Lifetime Warranty
• Lifetime Online Technical Support*
• Lifetime Next-Business-Day (NBD) Replacement

• ProSUPPORT OnCall 24x7 Service Packs**
• Category S2
• PMB0S12 (1 yr)
• PMB0S32 (3 yrs)
• PMB0S52 (5 yrs)

Package Contents

• NETGEAR Gigabit Ethernet PoE+ Unmanaged Switch
• Power adapter (localized to the country of sale)
• Wall installation kit & Rack-mount kit
• Quick install guide

Pour plus d'informations, vous pouvez consulter la page du produit sur le site du constructeur, disponible ICI
